The figures below show the wiring connections necessary to power a 3051S and enable communications with a hand-held Field Communicator.
Arrange the drip loop so the bottom is lower than the conduit connections and the transmitter housing.
#Rosemount 3095 ft manual install#
If applicable, install wiring with a drip loop. Plug and seal the unused conduit connection.Ĥ.
Use 24 AWG to 14 AWG wire and do not exceed 5,000 feet (1500 meters).ģ. For single compartment housing (Junction Box housing), shielded signal wiring should be used in high EMI/RFI environments. Power could damage the test diode in the test connection. Connect the positive lead to the “+” terminal, and the negative lead to the “–” terminal.ĭo not connect the power across the test terminals. Remove the housing cover labeled “Field Terminals.”Ģ. Use the following steps to wire the transmitter:ġ. Verify that the flange bolts are protruding through the isolator plate before applying pressure. Torque the bolts to the final torque value using the same crossing pattern. Torque the bolts to the initial torque value using a crossing pattern. However, no additional lubricant should be applied when installing either type of bolt.ģ. Carbon steel bolts do not require lubrication and the stainless steel bolts are coated with a lubricant to ease installation. Use the following bolt installation procedure:ġ. If bolt material is not shown in Figure 2, contact the local Emerson Process Management representative for more information. Confirm the material by viewing the markings on the head of the bolt and referencing Figure 2. Figure 1 illustrates common transmitter assemblies with the bolt length required for proper transmitter assembly.īolts are typically carbon steel or stainless steel. Use only bolts supplied with the transmitter or sold by Emerson as spare parts. If the transmitter installation requires assembly of the process flanges, manifolds, or flange adapters, follow these assembly guidelines to ensure a tight seal for optimal performance characteristics of the transmitters. Only use plugs, adapters, glands, or conduit with a compatible thread form when closing these entries.
#Rosemount 3095 ft manual manual#
Please review the approvals section of the 3051S reference manual for any restrictions associated with a safe installation. Installation of this transmitter in an explosive environment must be in accordance with the appropriate local, national, and international standards, codes, and practices. This document is also available electronically on WARNINGĮxplosions could result in death or serious injury: It does not provide instructions for diagnostics, maintenance, service, or troubleshooting. It also provides the basic electronics guidelines for the 3051SFA (reference manual document number 00809-0100-4809), 3051SFC (reference manual document number 00809-0100-4810), and 3051SFP (reference manual document number 00809-0100-4686). This installation guide provides basic guidelines for Rosemount 3051S transmitters (reference manual document number 00809-0100-4801). 6 North Street, Hepingli, Dong Cheng District Rosemount and the Rosemount logotype are registered trademarks of Rosemount Inc.īeijing Rosemount Far East Instrument Co.,
